Product Summary
The ISL83485IBZ-T is a 3.3V powered, single transceiver that meets both the RS-485 and RS-422 standards for balanced communication.
Parametrics
Absolute maximum ratings: (1)VCC to Ground:7V; (2)Input Voltages:DI, DE, RE:-0.5V to +7V; (3)Input/Output Voltages: A, B, Y, Z:-8V to +12.5V, RO:-0.5V to (VCC +0.5V); (4)Short Circuit Duration:Y, Z:Continuous; (5)Maximum Junction Temperature (Plastic Package):150℃; (6)Maximum Storage Temperature Range:-65℃ to 150℃; (7)Maximum Lead Temperature (Soldering 10s):300℃.
Features
Features: (1)Operate from a Single +3.3V Supply (10% Tolerance); (2)Interoperable with 5V Logic; (3)High Data Rates:up to 10Mbps; (4)Single Unit Load Allows up to 32 Devices on the Bus; (5)Low Current Shutdown Mode:15nA; (6)-7V to +12V Common Mode Input Voltage Range; (7)10ns Propagation Delay, 1ns Skew; (8)Full Duplex and Half Duplex Pinouts; (9)Current Limiting and Thermal Shutdown for driver ; (10)Overload Protection; (11)Pb-free available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ISL83485IBZ-T |
|
IC TXRX RS485/422 3.3V LP 8-S |
Data Sheet |
|
|
||||||
|
ISL83485IBZ-T7A |
|
IC TXRX RS485/422 SGL 8SOIC |
Data Sheet |
|
|
||||||
