Product Summary

The W25X20ALSNIG (2M-bit) Serial Flash memories provide a storage solution for systems with limited space, pins and power. The 25X series offers flexibility and performance well beyond ordinary Serial Flash devices. They are ideal for code download applications as well as storing voice, text and data. The devices operate on a single 2.3V to 3.6V power supply with current consumption as low as 5mA active and 1μA for power-down. All devices are offered in space-saving packages.

Parametrics

Absolute maximum ratings: (1)Supply Voltage, VCC: –0.6 to +4.0 V; (2)Voltage Applied to Any Pin, VIO at Relative to Ground: –0.6 to VCC +0.4 V; (3)Transient Voltage on any Pin, VIOT at <20nS Transient Relative to Ground: –2.0V to VCC+2.0V V; (4)Storage Temperature, TSTG: –65 to +150 ℃; (5)Electrostatic Discharge Voltage, VESD at Human Body Model: –2000 to +2000 V.

Features

Features: (1)Family of Serial Flash Memories: 2M-bit / 256K-byte (262,144); (2)SPI with Single or Dual Outputs: Clock, Chip Select, Data I/O, Data Out; Optional Hold function for SPI flexibility; (3)Data Transfer up to 100M-bits / second: Clock operation to 50MHz; Fast Read Dual Output instruction; Auto-increment Read capability; (4)Flexible Architecture with 4KB sectors: Sector Erase (4K-bytes); Block Erase (64K-byte); Page program up to 256 bytes <2ms; Minimum 100,000 erase/write cycles; 20-year retention; (5)Low Power Consumption, Wide Temperature Range: Single 2.3 to 3.6V supply; 5mA active current, 1μA Power-down (typ); -40℃ to +85℃ operating range; (6)Software and Hardware Write Protection: Write-Protect all or portion of memory; Enable/Disable protection with /WP pin; Top or bottom array protection.

Diagrams
