Product Summary

The LM6142BIM is a High Speed/Low Power 17 MHz Rail-to-Rail Input-Output Operational Amplifier. It provides new levels of performance in applications where low voltage supplies or power limitations previously made compromise necessary.

Parametrics

Absolute maximum ratings: (1)ESD Tolerance:2500V; (2)Differential Input Voltage:15V; (3)Voltage at Input/Output Pin:(V+) + 0.3V, (V-)-0.3V; (4)Supply Voltage (V+ - V-):35V; (5)Current at Input Pin:±10 mA; (6)Current at Output Pin:±25 mA; (7)Current at Power Supply Pin:50 mA; (8)Lead Temperature(soldering, 10 sec):260℃; (9)Storage Temp. Range:-65℃ to +150℃; (10)Junction Temperature:150℃.

Features

Features: (1)Rail-to-rail input CMVR -0.25V to 5.25V; (2)Rail-to-rail output swing 0.005V to 4.995V; (3)Wide gain-bandwidth: 17 MHz at 50 kHz (typ); (4)Slew rate:Small signal, 5V/μs, Large signal, 30V/μs; (5)Low supply current 650 μA/Amplifier; (6)Wide supply range 1.8V to 24V; (7)CMRR 107 dB; (8)Gain 108 dB with RL = 10k; (9)PSRR 87 dB.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM6142BIM
LM6142BIM

National Semiconductor (TI)

Operational Amplifiers - Op Amps

Data Sheet

0-190: $1.53
190-285: $1.50
285-570: $1.47
570-760: $1.44
LM6142BIM/NOPB
LM6142BIM/NOPB

National Semiconductor (TI)

Operational Amplifiers - Op Amps DUAL HI SPD/LOW PWR 17 MHZ RRIO OP AMP

Data Sheet

0-1: $2.83
1-10: $2.54
10-25: $2.27
25-50: $2.14
LM6142BIMX/NOPB
LM6142BIMX/NOPB

National Semiconductor (TI)

Operational Amplifiers - Op Amps

Data Sheet

0-1: $2.83
1-10: $2.54
10-25: $2.27
25-50: $2.14
LM6142BIMX
LM6142BIMX

National Semiconductor (TI)

Operational Amplifiers - Op Amps

Data Sheet

0-2500: $1.42
